VPX Backplanes

Precision engineered backplanes designed to the highest performance standards are essential for the high speed signal demands prevalent in today’s defense applications. Our backplanes represent a key technology that supports the critical performance expectations of our line of ATR and rackmount chassis for VPX and SOSA aligned module content. As signal speed requirements reach toward 100Gb and beyond, LCR is committed to delivering backplane solutions that meet the highest levels of signal integrity in the industry.

Precision engineered backplanes designed to the highest performance standards are essential for the high speed signal demands prevalent in today’s defense applications. Our backplanes represent a...

Download Backplane Brochure
Ask About VPX Backplanes

More Product Details

General Features

100 GbE (100GBASE-KR4) and PCI Express® (PCIe) Gen-4 on data plane, control plane and expansion plane fabrics

VPX and SOSA aligned module profiles

Custom designs to meet your specific application requirements

VITA 66 and 67 optical and RF I/O connectors and apertures

VITA 46 Multigig RT-3 or EVO 2.0VPX connectors for superior signal integrity

Hybrid 3U / 6U backplanes and hybrid VPX / VME

High Speed Signal Support

High performance FR4 PCB material

PCIe Gen 4 signaling

100G-baseKR4 protocols

Exceeding ANSI/VITA 68.1- 2017 performance levels

IEEE 1588 radial clock slot supporting precision timing protocol and network synchronization
