6U Backplane LCR
Standard and Custom 6U VPX Backplanes

6U VPX backplanes bring unmatched data rates to larger format VPX systems where high data handling capacity takes precedence over space constraints. Our 6U VPX backplane designs support new and emerging SOSA aligned slot profiles as well as existing VITA 65 slot profiles with full and half width apertures for VITA 66 and 67 optical and RF interconnects.

Our experienced engineering staff will work with you to develop the specific backplane profile to support the data flow and slot profiles necessary for your targeted application. Our backplanes ensure the highest levels of signal integrity at 10Gbps data rates per lane with ongoing efforts to support speeds up to 25Gbps per lane.

We offer power and ground pass through backplanes for your initial development efforts or backplanes pre-populated with selected slot profiles for later stage application development. LCR offers VPX cabling solutions from Meritec and our application engineers can guide you through cable options for your application.

  • Slot counts from 1 through 18
  • Custom topology supporting your payload module profiles
  • Power and ground versions for initial development
  • Backplanes pre-populated with selected slot profiles
  • Support for 1000BASE-BX, 1000BASE-KX, 10GBASE-KX4, 10GBASE-KR, or 40GBASE-KR4


See our 3U VPX backplanes
